    Gp33 3 Phase Low Frequency Ups Industrial 10-200kva With Rs232 Communication Interface

    Ask Lasest Price
    Brand Name : G-Tech
    Model Number : Low Frequency Online UPS
    Certification : CE, ISO,SGS
    Price : negotiation
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 500 pcs per month
    Delivery Time : 20~25days
    • Product Details
    • Company Profile

    Gp33 3 Phase Low Frequency Ups Industrial 10-200kva With Rs232 Communication Interface

    Product Description:

    GP33 3 Phase Industrial Online UPS 10-200KVA Low Frequency's advanced battery charging system enables the UPS to supply a long backup time while the charging time is rather short, and its temperature compensation system can help to prolong the service life of the vattery. Also, its circuit is simple, which reduces the number of components and makes the machine more compact and more reliable.

    Its ture double-cpn version online technology provides pure and safe power supply to all appliances, communication equipment and important loads connected to the internet, and the DSP technology responds quickly to different power supply problems, making sure its load will work uninterruptedly.

    It is compatible to all kinds of loads and widely used in the fields of energy sources, transportion, office, medical equipment, engine-room, data center, toll station and so on.


    • 10KVA-200KVA
    • 384Vdc
    • 380Vac / 220Vac
    • 380Vac / 220Vac
    • GP33

    Technical Parameters:

    Feature:

    1. High-efficient DSP chip

    2. Outstanding electric property

    3. Good looking and excellent hardware

    4. N+X parallel redundancy (compatible to battery share in the parallel mode)

    5. Frontal-board operation and maintenance

    6. Twin-channel line input

    7. Remote monitoring

    8. Intelligent management of battery charging and discharging

    9. Flexible battery arrangement

    10. Flexible arrangement, change due to the need.


    Model #GP33 series
    Capacity10KVA15KVA20KVA30KVA40 KVA60KVA80KVA100KVA120KVA160KVA200KVA
    INPUT
    voltage(208/308/400/480Vac) ± 20% / 5 wires (3 lines + neutral + ground)
    frequency50/60Hz ± 10% Auto sensing
    power factor0.98
    filterEMI, RFI
    dual inputoptional
    OUTPUT
    voltage(208/308/400/480Vac) ± 20% / 5 wires (3 lines + neutral + ground)
    frequency50/60Hz ± 1% Auto sensing
    EfficiencyAC/AC>92%
    transfer time0 ms
    wave formsine wave
    power factor0.8
    voltage T.H.D.<2% with linear load
    crest factor3:1
    technologytrue on-line double conversion controlled by microcontroller
    overload recoveryautomatically transfer to UPS mode
    Isolation transformerinverter mode (bypass mode is optional)
    parallel connectionparallel connection function is ready (extra PCB is not reuired)
    BATTERY
    battery typeVRLA (valve regulated lead acid), not included
    DC voltage384 Vdc
    charging time4 hours up to 90%
    battery detectionself-detect, transfer to battery mode adjustable
    PROTECTION
    lightning and transient protectionhot swappable lightning and transient surge suppressor (in:10Kamp, Up:1.5 Kv, I max: 20 Kamp.)
    harware protectioninput breaker, output breaker, battery breaker, bypass breaker; DC fuse, fan, redundant power supply; temperature sensor, EPO (Emergency Power Off), audible alarms etc.
    software protectiondischarging batteries, battery charger working mode, inverter working mode, emergency power off, manual shutdown, bypass SCR failure, bypass sequence failure, bypass over the limit, critical overload, batteries exhaustion, low or high output voltage, DC fuse open, 5V power supply failure, 13.5 power supply failure, inverter overvoltage, 200% overload on each line, transfer failure, inverter voltage out of range, over voltage betweenneutral and ground, UPS on bypass mode, bypass frequency out of range.
    bypasssolid state
    overload125% for 10min, 150% for 30sec, 1000% for 16 millisecond
    EPOEPO local and/or remote
    DisplayLCD, touch screen
    LED diagramincluded
    communicationRS232 intelligent slot, modem, SNMP(RJ45) (SNMP adaptive software is supplied by the producer)
    ENVIRONMENT
    elevation1.700 m.o.s.l without derrating
    temperature & noise0℃~40℃/<60dB @1.5m.
    humidity0~95% non condensate
    PHYSICAL
    Unit dimension (mm)L830*W402*H1050L664*W865*H1548L966*W890*H1748L1160*W1043*H1900
    Net weight (1pc, kg)152.5167.5193.5222.5362.55434.05534.05670.05746.0511201320

    Applications:

    GP33 3 Phase Industrial Online UPS 10-200KVA Low Frequency is a reliable power supply unit that provides a stable and uninterrupted power supply with low frequency.

    Application to office, computer facilities and industrial environments


    Advanced communication function:

    With the use of communication interface and monitoring software, you can monitor this UPS on your computer, which simplifies the management of power supply. You can also choose to buy a SNMP card, which is compatible to all kinds of operating system, and supports TCP/IP, SNMP,HTTP protocol, so as to monitor the UPS through internet. Moreover, it will be easier to achieve central maagement even users are scattered in different places and it can also diagnose network and maintain the system remotely, realizing global managemnent in a very real sense.


    Software monitoring through RS232.

    Monitoring through network adapter.

    Monitoring through GPRS

    Packing and Shipping:

    Packaging and Shipping for Low Frequency Online UPS

    Packaging of Low Frequency Online UPS needs to be done with utmost care to avoid any form of damage to the units during transit. The best practice is to use corrugated cardboard boxes with inner cushioning material like foam, bubble wraps, etc. for extra safety. Proper labeling should be done to avoid any form of mishandling.

    Shipping of Low Frequency Online UPS needs to be done with reliable carriers with tracking. The best practice is to opt for express shipping for quick delivery and to avoid any form of delay and damage to the units.
