    Uninterruptible 3KVA 10KVA High Frequency Online Ups Power Supply

    Ask Lasest Price
    Brand Name : G-Tech
    Model Number : Tower UPS
    Certification : ISO, CE, ROHS
    Payment Terms : L/C, T/T, Western Union
    Delivery Time : 30 days
    Price : Negotiation
    • Product Details
    • Company Profile

    Uninterruptible 3KVA 10KVA High Frequency Online Ups Power Supply

    Uninterruptible Power Supply 1KVA2KVA 3KVA 6KVA 10KVA Online High Frequency Ups Rack 19" 2U
    Tower type Power factor 1.0 Uninterruptible Power supply 1KVA-10KVA
    Online High frequency UPS 1-12A adjustable Charger current 1KVA 2KVA 3KVA 6KVA 10KVA
    Single phase input single phase output
    This series of UPS applies CPU integrated control technology, which allows UPS to response promptly and accurately when power outage, high or low voltage, surge, transient or spike occurs so on. It possesses automatic startup function, automatic voltage regulation function and a wide range of input voltage, so it is applicable to all kind of electric power environment. In addition, its design is humanized and elegant with LED or LCD display, those are two alternatives.

    Production Introduction

    This series UPS applies CPU intergrated control technology, which allows UPS to response prometly and accurately when power outage, high or low voltage, surge, transient or spike occurs while its protection port provides protection for special external devices, such as printers and so on. It possess automatic startup function,automatic voltage regulation function and a wide range of input voltage, so it is applicable to all kinds

    of electric power environment. In addition, its design is humanized and elegant with LED or LCD display, those are tow alternatives.


    Model #PT-1KSPT-1KLPT-2KSPT-2KLPT-3KSPT-3KL
    Capacity1KVA / 1KW2KVA / 2KW3KVA /3KW
    DisplayLCD
    INPUT
    Voltage rangeFull load85~140 VAC or 160~280 VAC
    half load55~150 VAC or 110~300 VAC
    Frequency Range40Hz~70Hz
    PhaseSingle phase with ground
    Power factor≥ 0.99 @ 220-230 VAC (input voltage)
    OUTPUT
    Output voltage range100/110/115/120/127VAC or 200/208/220/230/240VAC
    AC Voltage Regulation± 1% (Batt. Mode)
    Frequency RangeLine Mode: (Synchronized Range) , Batt. Mode: 50/60Hz±0.1%
    OverloadLine Mode: 1min@105%~125%Load 30s@125~150% Load 0.5ms@>150%Load
    Current Crest Ratio3:1
    Harmonic Distortion≤2% THD (Linear load); ≤5% THD (non-linear load)
    Transfer timeAC Mode to Batt. Mode: Zero
    Inverter to Bypass: 4ms (Typical)
    Wave form (Batt. Mode)Pure Sine Wave
    EFFICIENCY
    AC ModePeak efficiency 93%Peak efficiency 94%Peak efficiency 94%
    Full load efficiency 90%Full load efficiency 91%Full load efficiency 91%
    BATTERY
    Battery type ( standard model)12 / 7AH
    Capacity & quantity of battery2pcs*12V7Ah-------6(4)pcs*12V7Ah-------6(8)*12V7Ah-------
    External battery norminal DC voltage-------36VDC-------72VDC-------96VDC
    Recharge Time4 hours recover to 90% capacity ( Typical) , depends on users' needs
    Charging Current1.0 (default) 1~12A(settable) External battery pack1~12A(settable)1.0 (default) 1~12A(settable) External battery pack1~12A(settable)1.0 (default) 1~12A(settable) External battery pack1~12A(settable)
